Ubiquiti | U7 Lite Access Point

0 reviews 0 sold. Only 1 remain

$155.00

Ex Tax: $155.00

Brand: UBIQUITI

Product Code: Ubiquiti | U7 Lite Access Point

Stock In Stock

Qty

Add to wishlist
Add to compare

Tags: Ubiquiti | U7 Lite Access Point

Categories Cart Account Search Recent View Go to Top

Product Description

Dimensions
Ø171.5 x 33 mm
(Ø6.8 x 1.3")
WiFi Standard
WIFi 7
Spatial Streams
4
Coverage Area
115 m² (1,250 ft²)
Max. Client Count
200+
Uplink
2.5 GbE
Mounting
Ceiling, Wall
(Lite Mount Included)
Power Method
PoE

Performance
MIMO
5 GHz : 2 x 2 (DL/UL MU-MIMO)
2.4 GHz : 2 x 2 (DL/UL MU-MIMO)
Max. Data Rate
5 GHz : 4.3 Gbps (BW240)
2.4 GHz : 688 Mbps (BW40)
Antenna Gain
5 GHz : 5 dBi : 2.4 GHz : 4 dBi
Max. TX Power : 5 GHz
24 dBm
2.4 GHz : 23 dBm
Max. BSSIDs
8 per Radio
Supported Data Rates
802.11be (WiFi 7)
7.3 Mbps to 4.3 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/240)
802.11ax (WiFi 6)
7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160)
802.11ac (WiFi 5)
6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160)
802.11n
6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)

Features
Wireless Meshing : ✓
Band Steering : ✓
802.11v BSS Transition Management : ✓
802.11r Fast Roaming : ✓
802.11k Radio Resource Management (RRM) : ✓
Advanced Radio Management : ✓
Passpoint (Hotspot 2.0) : ✓
Captive Hotspot Portal
Custom Branding Landing Page : ✓
Voucher Authentication : ✓
Payment-Based Authentication : ✓
External Portal Server Support : ✓
Password Authentication : ✓
Guest Network Isolation : ✓
Private Pre-Shared Key (PPSK) : ✓
WiFi Speed Limiting : ✓
Client Device Isolation : ✓
WiFi Schedules : ✓
RADIUS over TLS (RadSec):✓
Dynamic RADIUS-assigned VLAN:✓

Hardware
Max. Power Consumption
13W
Supported Voltage Range : 42.5—57V DC
Networking Interface
(1) 2.5 GbE RJ45 port
Weight : 313 g (11 oz)
Management
Ethernet : Enclosure Material
UV-stabilized polycarbonate
Mount Material
UV-stabilized polycarbonate, galvanized steel (SGCC)
LEDs
System : White/Blue
Channel Bandwidth : HT 20/40, VHT 20/40/80/160, HE 20/40/80/160, EHT 20/40/80/160/240 (MHz)
NDAA Compliant : ✓
Certifications
CE, FCC, IC, SRRC, Anatel: 02143-25-08356
Ambient Operating Temperature
-30 to 40° C (-22 to 104° F)
Ambient Operating Humidity
5 to 95% noncondensing
